Door lock PZ AVERS 50/85/195/18mm black

The Door lock PZ AVERS 50/85/195/18 mm black is an Avers lock body designed for standard doors with a 50 mm backset and an 85 mm mounting point. It is suitable for residential and office doors that need a reliable security solution and fits older doors that use a conventional fixing system.

The body measures 195 mm in height, 76 mm in width and 14 mm in thickness, with a plate thickness of 18 mm. The backset (distance from the edge to the cylinder centre) is 50 mm and the distance between the link and cylinder (mounting point) is 85 mm. Model reference is PZ 81672. All dimensions are provided to ensure quick and correct installation.
